Ford Truck Models Towing Capacity
Tow More with Your New Ford Truck
The new Ford truck lineup is more diverse than ever, with models ranging from the compact Maverick to the heavy duty Ford F-350. With so many trucks to choose from, it can be hard to know which one is right for you. But when you account for towing capacity, it can be easier to understand which truck you need for your Eureka lifestyle, and Mangold Ford is here to help.
Tow More with the Ford F-150
In general, the 2024 Ford F-150 has an impressive towing capacity that ranges from approximately 5,000 pounds for the base models with the 3.3L V6 engine to an astonishing 14,000 pounds for the high-performance models equipped with the 3.5-liter EcoBoost V6 engine. The PowerBoost® engine is a game-changer, combining a twin-turbocharged 3.5L V6 with a 35-kilowatt electric motor to deliver exceptional power and efficiency, making it an ideal choice for those who require maximum towing capability without sacrificing fuel efficiency. With this hybrid powertrain on board, you can have an F-150 model that tows up to 12,700 pounds.
The F-150 achieves such remarkable towing prowess through a combination of advanced engineering, strong chassis design, and innovative towing technologies. Features such as the available Pro Trailer Backup Assist™, Trailer Reverse Guidance, and the Smart Trailer Tow Connector enhance the towing experience, making it more intuitive and convenient for drivers.
| Engine | HP @ RPM | Torque @ RPM | Max Towing (lbs) | Max Payload (lbs) |
|---|---|---|---|---|
| 3.3L Ti-VCT V6 | 290 @ 6,500 | 265 lb-ft @ 4,000 | 8,200 | 1,985 |
| 2.7L EcoBoost V6 | 325 @ 5,000 | 400 lb-ft @ 3,000 | 10,100 | 2,480 |
| 3.5L EcoBoost V6 | 400 @ 6,000 | 500 lb-ft @ 3,100 | 14,000 | 3,250 |
| 5.0L Ti-VCT V8 | 400 @ 6,000 | 410 lb-ft @ 4,250 | 13,000 | 3,325 |
| 3.5L PowerBoost Full Hybrid V6a | 430 @ 6,000 | 570 lb-ft @ 3,000 | 12,700 | 2,120 |
Ford F-250 Towing Capacity
The Ford F-250 is a powerhouse in the heavy-duty truck category, offering Washington drivers impressive towing capabilities that cater to a variety of needs. The towing capacity of the F-250 can vary depending on the chosen engine, drivetrain, and additional towing packages.
In general, the 2024 Ford F-250 has a substantial towing capacity that ranges from 14,200 pounds for the base models equipped with the 6.8L V8 engine to an impressive 22,000 pounds or more for the higher-end configurations featuring the 6.7L Power Stroke® Turbo Diesel V8 engines. The diesel engine is a popular choice among F-250 enthusiasts for its remarkable torque and towing prowess, making it an ideal option for those who require maximum towing capability.The F-250 achieves its robust towing performance through a combination of a durable chassis, powerful engine options, and advanced towing technologies. Features such as the available Trailer Reverse Guidance and Pro Trailer Backup Assist™ enhance the towing experience, making it more accessible and efficient for Metamora drivers, especially when navigating tight spaces or challenging terrains.
| Engine | HP @ RPM | Torque @ RPM | Max Towing (lbs) | Max Payload (lbs) |
|---|---|---|---|---|
| 6.2L N/A V8 Gas | 385 @ 5,750 rpm | 430 @ 3,800 rpm | 13,300 4x2/12,900 4x4. | 3,550 to 4,160* |
| 7.3L N/A V8 Gas | 430 @ 5,500 rpm | 475 @ 4,000 rpm | 14,000 4x2/15,000 4x4lbs. | 3,550 to 4,160*. |
| 6.7L Power Stroke® V8 Turbo Diesel | 475 @ 2,600 rpm | 1,050 @ 1,600 rpm | 15,000 lbs. | 3,550 to 4,160* |
These numbers are based off the F-250 Super Duty. *Depending on configuration
The Ford F-150 Lightning Delivers Instant Torque for Easy Towing
The F-150 Lightning takes the exceptional towing capabilities of the traditional F-150 into the realm of electric vehicles. As the first all-electric F-Series truck from Ford, the F-150 Lightning redefines what is possible in terms of electric-powered towing.
When properly equipped, rear-wheel drive Ford F-150 Lightning models can tow up to 17,100 pounds. This includes the Extended Range Battery and Max Tow Package. And the minimum tow capacity for the Lightning comes from the 4x4 model with standard range battery. The reduced battery weight and added heft of the 4x4 system drop total tow rating to 5,000 pounds.
Regardless of trim, the F-150 Lightning benefits from advanced technology that simplifies the towing process. The available Ford Intelligent Backup Power feature allows the F-150 Lightning to serve as a mobile power source, enabling users to power tools, appliances, or even their home during power outages or off-grid activities.
Ford Ranger Towing Capacity
The Ford Ranger offers a step up in terms of towing capacity while maintaining a manageable size for everyday use. The 2024 Ford Ranger is designed to handle a wide range of towing needs, from recreational pursuits to work-related tasks.
The towing capacity of the Ford Ranger varies based on the chosen engine and drivetrain configuration. The Ranger equipped with the 2.3L EcoBoost® engine and the available Trailer Tow Package, boasts an impressive maximum towing capacity of up to 7,500 pounds. The Trailer Tow Package includes features like a Class IV trailer hitch receiver, a 4/7-pin wiring harness, and a higher-capacity radiator to ensure efficient cooling during towing.
With its robust towing capabilities, the Ranger is well-suited for towing small boats, trailers, and even midsize campers. Whether you're heading to the lake for a weekend getaway or hauling equipment to the job site, the Ranger showcases its versatility as a midsize truck with the towing muscle to match.
| Engine | HP @ RPM | Torque @ RPM | Max Towing (lbs) | Max Payload (lbs) |
|---|---|---|---|---|
| 2.3L EcoBoost 4x2 | 270 hp @ 5,500 rpm | 310 lb-ft @ 3,000 rpm | 7,500 lbs. | 1,905 lbs |
| 2.3L EcoBoost 4x4 | 270 hp @ 5,500 rpm | 310 lb-ft @ 3,000 rpm | 7,500 lbs. | 1,696 lbs. |
Ford Maverick Towing Capability
The Ford Maverick stands out as a fuel-efficient and agile option in the Ford lineup. Despite its smaller footprint, the Maverick doesn't compromise on towing capabilities. The 2024 Ford Maverick offers a maximum towing capacity of up to 4,000 pounds when equipped with the available 2.0L EcoBoost® engine and the optional Tow Package.
The Tow Package is a noteworthy addition for those with towing needs, as it includes features such as a trailer hitch receiver, a trailer sway control system, and a 4-pin wiring harness. With these enhancements, the Maverick demonstrates its ability to handle a variety of trailers, including small boats, utility trailers, or even lightweight campers.
| Engine | HP @ RPM | Torque @ RPM | Max Towing (lbs) | Max Payload (lbs) |
|---|---|---|---|---|
| 2.5L FHEV (Hybrid) | 191 @ 5,600 | 155lb-ft @ 4,000 | 2,000 lbs. (FWD Only) | 1,500 lbs |
| 2.0L EcoBoost (Gas engine) | 250 @ 5,500 | 277 lb-ft @ 3,000 | 2,000 lbs./4,000 w/ tow package | 1,500 lbs |
Handle Anything with a Ford F-350
Stepping up to the Ford F-350 brings even greater towing capabilities, as it is designed for heavier loads and more challenging towing scenarios. The F-350 is a favorite among those who require uncompromising strength and capability for both work and recreational purposes.
The 2024 Ford F-350 showcases an impressive towing capacity, ranging from approximately 18,200 pounds for the base models with the 6.8L gas-powered V8 engine to a staggering 32,500 pounds for the top-tier configurations equipped with the 6.7L Power Stroke® Turbo Diesel V8 engine. The diesel engine, with its exceptional torque and towing capabilities, remains a popular choice for F-350 enthusiasts tackling heavy-duty towing tasks.
Similar to the F-250, the F-350 benefits from advanced towing features such as the available Trailer Reverse Guidance, Pro Trailer Backup Assist™, and the Ultimate Trailer Tow Camera System. These technologies not only enhance the towing experience but also contribute to the overall safety and confidence of Carlock drivers when hauling substantial loads.
Visit Our Dealership to Learn More
Learn more about the various configurations and additional towing accessories available on every new Ford truck when you visit our Ford dealership near El Paso, IL today!
